CABINET PARTS
2
W10283342
For Model: IX5HHEXWS01
(Stainless Steel)
W10297587
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10270272
Use & Care Guide
W10270376
Energy Guide
W10238844
Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Cover, Left Hinge
B5759655 Black
4 B5759649 Gasket
5 Roller Assy.
W10275849
Right
W10275850
Left
6 10354002 Foot, Brake
7
12566607ED
Hinge, Left Top
9 67006521 Screw
10 Cover, Right Hinge
12684202B
Black
11 12990101 Screw
12 12698403 Block, Pivot
14 12992403 Screw (3)
15 Hinge, Center (LT)
13000007ED
Black
16
12566606ED
Hinge, Right Top
17 Cover, Corner
12587703B
Black
20 12991302 Screw (4)
21
W10211854
Cover, Unit
22 Grille, Toe
W10244561
Black
24
W10210988
Tube, Drain
25 12990511 Screw
26 12820505 Fiber, Acoustic
31 12579702 Shim, Top Hinge
32 12990303 Screw, Block
33 Hinge, Center (RT)
13000008ED
Black
34
W10208592
Guard−Water Valve
35
W10216614
Sweep−Water Valve
