FREEZER LINER PARTS
4
For Model: IX5HHEXWS01
(Stainless Steel)
W10297587
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 A3189392 Gasket, Foam (2)
4 12804901 Cover, Light
6
12570701V
Socket, Light
8 12990521 Screw (8)
9
W10194422V
Bulb, Light
10
12476401V
Housing, Frz. Light
11 12226112 Cover, Evaporator
12 12990101 Screw (7)
13 Bracket, Door
W10122147
Left
W10122148
Right
14 12805001 Housing, Lighting
15 13058002 Clip, Evap. Motor
16 12466105 Switch, Light
18 Cradle, Basket
W10280608
Left
W10280613
Right
19
W10120018
Slide, Drawer (2)
20 A3189397 Gasket, Bottom
21 Adapter, Slide
W10261203
Left
W10261204
Right
22 13024803 Cover, Fan Shroud
23 13057901 Shroud, Evap.Fan
24 2169142 Fan, Evaporator
25
W10121318
Grommet (2)
26
W10128551
Motor, Evaporator
27 D7753903 Funnel, Drain
(Incl. # 28 & 29)
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 12815301 Cover, Thermistor
32 12990501 Screw (6)
33
12991603V
Screw
34
W10157765
Diverter, Air
35 Rack−Side
W10284694
Left Side
W10284695
Right Side
Following Parts Not Illustrated
13014801 Harness, Lights
(Freezer)
To Next Page
