IKEA KULINARISK User Guide

Symbol Submenu Description
Set + Go When ON, in the Select Options window you can
choose the function: Set + Go.
Heat + Hold When ON, in the Select Options window you can
choose the function: Heat + Hold.
Time Extension Activates and deactivates the time extension
function.
Display Contrast Adjusts the display contrast by degrees.
Display Brightness Adjusts the display brightness by degrees.
Set Language Sets the language for the display.
Buzzer Volume Adjusts the volume of press-tones and signals by
degrees.
Key Tones Activates and deactivates the tone of the touch
fields. It is not possible to deactivate the tone of
the ON / OFF touch field.
Alarm/Error Tones Activates and deactivates the alarm tones.
Service Shows the software version and configuration.
Factory Settings Resets all settings to factory settings.
Heating Functions
Heating function Application
True Fan Cooking To bake on up to 3 shelf positions at the same
time and to dry food. Set the temperature 20 - 40
°C lower than for the function: Top/Bottom Heat.
True Fan + Steam To steam dishes. Use this function to decrease the
length of the cooking time and to preserve the vi-
tamins and nutrients in the food. Select the func-
tion and set the temperature between 130 °C to
230 °C.
Top/Bottom Heat To bake and roast food on 1 shelf position.
ENGLISH 13

IKEA KULINARISK Specifications

General

Type	Built-in oven
Energy class	A
Cleaning	Pyrolytic
Cord Length	1.5 m
Voltage	220-240 V
Frequency	50/60 Hz
Number of heating elements	4
Light	Yes
Door	Triple glazed
Color	Stainless steel
Material	Stainless steel
Dimensions	595 x 595 x 550 mm
Functions	Defrost
