IKEA LUFTIG User Manual

10
ENGLISH
Technical Data
Unit Value
Product Type Wall mounted hood
Dimension
Width mm 598
Depth mm 471
Height min/max mm 620/995
Airow max* - Exhaust m3/h 400
Noise max* - Exhaust dBA 64
Airow max* - Recirculating m3/h 270
Noise max* - Recirculating dBA 72
Total Power W 161
Lamps info
Halogen Bulb
2 x 28W
E14
Installation minimum height - gas hob mm 650
Installation minimum height - elec hob mm 500
Net Weight Kg 6,4
This appliance has been designed,
manufactured and marketed in compliance with
the E.E.C. Directives.
The technical information is situated in the rating
plate on the internal side of the appliance.
* Maximum speed (boost excluded).

IKEA LUFTIG Specifications

General

Width	60 cm
Voltage	220-240V
Number of grease filters	1
Light bulb included	Yes
Bulb type	LED
Material	Stainless steel
Frequency	50 Hz
Type	Wall-mounted
Filter type	Grease
