IKONIX SCI 290 Series User Manual

hipot.com 50
Memory Location Edits and Companion Queries
The following commands are used to create or modify Test Setup at each Memory Locations.
FL <memory location number> - Load a memory location from non-volatile memory into random access memory RAM.
The parameter values should use complete text and not use the coded values that are associated with the individual parameter
setting commands. Such as “ON” and “OFF” and any toggle eld that use words or phrases like “OPEN”, “CLOSE”. The LS?
companion command will also list all parameters in complete text as they appear on the setting screen.
FL? - Query the memory location of the current selection.
Command Description Value
FL <memory location number> Load Test Located at
Memory Location
Memory location number = 1-5
FL? Query Memory
Location
1-5
SAA Add ACW Test
SAD Add DCW Test
SAI Add IR Test
ADD <ACW,p,p,p,p,p,p,p,p,p,p,p> Add all parameters for
ACW Test
ACW, Voltage(kV), HI-Limit(mA), LO-Limit(mA), Ramp(s),
Dwell(s), Continuity(ON/OFF), Cont. HI-Limit(Ω), Cont.
LO-Limit(Ω), Cont. Oset(Ω), Frequency, Connect(ON/OFF)
ADD <DCW,p,p,p,p,p,p,p,p,p,p> Add all parameters for
DCW Test
DCW, Voltage(kV), HI-Limit(mA), LO-Limit(mA), Ramp(s),
Dwell(s), Continuity(ON/OFF), Cont. HI-Limit(Ω), Cont.
LO-Limit(Ω), Cont. Oset(Ω), Connect(ON/OFF)
ADD <IR,p,p,p,p,p,p> Add all parameters for
IR Test
IR, Voltage(V), HI-Limit(Ω), LO-Limit(Ω), Ramp(s), Delay(s),
Connect (ON/OFF)
ACW DCW IR
1 Voltage Voltage Voltage
2 HI-Limit HI-Limit HI-Limit
3 LO-Limit LO-Limit LO-Limit
4 Ramp Up Ramp Up Ramp Up
5 Dwell Dwell Delay
6 Continuity (ON/OFF) Continuity (ON/OFF) Connect (ON/OFF)
7 Continuity HI-Limit Continuity HI-Limit
8 Continuity LO-Limit Continuity LO-Limit
9 Continuity Oset Continuity Oset
10 Frequency Connect (ON/OFF)
11 Connect (ON/OFF)
