Turn and press the rotary knob to enter the reading of the standard AC Voltmeter into the tester. Once all digits are entered
the tester will advance to the next calibration point.
Then the display will show a value around 8 Volts.
Turn and press the rotary knob to enter the reading of the standard AC Voltmeter into the tester. Once all digits are entered
the tester will advance to the next calibration point.
Then the display will show a value around 1000 Volts.
Turn and press the rotary knob to enter the reading of the standard AC Voltmeter into the tester. Once all digits are entered
the tester will advance to the next calibration point.
3. To calibrate DC Voltage
Please connect a standard 6000V DC Voltmeter to the HV and RETURN connectors.
Rotate the yellow knob until the display shows:
Then press the TEST button on the front panel. The tester will provide around 6000VDC on the output connectors and the
display will show:
Then the display will show a value around 6000 Volts.
Turn and press the rotary knob to enter the reading of the standard AC Voltmeter into the tester. Once all digits are entered
the tester will advance to the next calibration point.
Press the TEST button again on the front panel. The tester will provide around 1000VAC on the output connectors and the
display will show:
Then the display will show a value around 1000 Volts.
Turn and press the rotary knob to enter the reading of the standard AC Voltmeter into the tester. Once all digits are entered
the tester will advance to the next calibration point.
