iLive IJMB484B - Front Control

BRIGHT
CONTRAST
VERTICAL HOLD
VIDEO OUTPUT JACK
(See page 06)
AUDIO OUTPUT JACK
(R) (See page 08)
AUDIO OUTPUT JACK
(L) (See page 08)
DC POWER INPUT
(See page 06)
Introduction
Front Control
POWER INDICATOR
POWER BUTTON
FUNCTION CONTROL
ECHO CONTROL
BALANCE CONTROL
STOP BUTTON
PROGRAM BUTTON
MIC 1 INPUT
CD DOOR
HEADPHONE JACK
MIC 1 VOLUME
CONTROL
MIC 2 VOLUME
CONTROL
VOLUME CONTROL
PLAY/ PAUSE
BUTTON
FAST FORWARD
(SKIP SEARCH)
BUTTON
MIC 2 INPUT
FAST BACKWARD
(SKIP SEARCH)
BUTTON
BLUETOOTH
INDICATOR
PLAY/ PAUSE
INDICATOR
REPEAT BUTTON
PROGRAM INDICATOR
REPEAT INDICATOR
LED DISPLAY
Rear Control
AVC
LIN E IN
MIC 2 V OLECH O
MIC 1 MIC 2
MIC 1 V OL
FUNCTION
LINE INCD
CDG
P
A
I
R
I
N
G
