Mounting
Mounting the Unit to the Wall
1. Decide whether or not to use spacers
behind the wall mount brackets.
2. Locate 2 studs in the wall.
Most houses have the studs
spaced on 16 inch centers.
3. Screw the wall mount brackets and any
spacers used into two parallel studs
using two screws in each bracket.
4. Be sure that the wall mount brackets
are level with each other.
5. Hang the unit onto the secured
wall mount brackets.
To ensure a reliable and sturdy
installation, please consult a professional
before mounting the unit to the wall.
The included spacers can be used in
combination to adjust unit’s distance from
the wall in order to match a mounted Flat-
Panel TV. The spacers are 1/4”, 1/2”, 3/4”, 1”.
If spacers are in place, use the long screws. If
spacers are not needed, use the short screws.
