iLive ITB284B - Orientation; Speaker Rear Inputs; Speaker Controls (Left Side)

6
OPTICAL IN DC IN
R
SUB OUT
L
AUX IN
LINE IN
VOLUME +
PAIR
VOLUME
SOURCE
POWER
Speaker Controls (Left Side)
Speaker Rear Inputs
Orientation
Stereo RCA Audio
Inputs (AUX IN)
Optical Input
DC Power Input
Power
Press to power
the unit on or off.
Source
Press to switch
between Optical,
Line In, AUX, and
Bluetooth modes.
Volume
Press to adjust the
volume up or down.
Pair
Press and hold to
begin pairing to a
Bluetooth device.
Line In
Subwoofer Output
