Illusion Esprit 62 - Features, Parts, and Troubleshooting; Parts Assembly and Identification

ESPRIT INBUILT MANUAL 2014
Quality & Value In Gas Log Fires
11. OUTER CASE TOP PANEL
12. GAS VALVE ASSEMBLY
13. FAN ASSEMBLY
14. BASE PANEL
15. HEAT SHIELD WRAPPER
16. OUTER CASE WRAPPER
PARTS ASSEMBLY EXPLODED VIEW
1. DOOR ASSEMBLY
2. LHS BOTTOM COVER
3. BOTTOM DOOR PANEL
4. RHS BOTTOM COVER
5. LHS WING
6. RHS WING
7. MANTEL BOTTOM
8. MANTEL TOP
9. MANTEL DUCT
10. HEAT SHIELD TOP PANEL
1
2
3
4
10
9
8
7
6
5
11
13
14
16
12
Spare Parts
Spare parts are available from
your supplier. Refer to page 17
for contact details.
21
15
