illy SMART30 I - Machine Components

20
18
Machine components
1. Capsule loading lever
5. Drip grid
6. Drip tray and capsule
receptacle(removable)
8. Water tank
(removable)
9. Plug
7. Power lead
B. Big cup
A. Small cup
2. Dispensing buttons
4. Dispensing
spout
3. Small cup support
