MACHINE PARTS
A
B
C
E
D
F
G
H
I
L
O
A LEVER TO OPEN/CLOSE CAPSULE
COMPARTMENT
B CAPSULE COMPARTMENT (internal)
C BREW GROUP
D MACHINE ON INDICATOR LED
E HEATED CUP HOLDING SURFACE
F COFFEE BREW BUTTON
(when LED illuminates, machine is at requi-
red temperature).
M
N
G USED CAPSULE CONTAINER
(also contains some residual liquid left after
brewing)
H CUP STAND
I DRIP TRAY (internal)
L WATER TANK
M MAIN ON/OFF SWITCH
N POWER CORD
O DATA PLATE (on base)
