3 of 4/August 2006
Quick Setup Instructions UDC-5212 and DTD-5225 Digital Clocks
4. Setting the Clock Secondary Reference Source
If the UDC/DTD is set to Clock mode, you can use DIP switch 4 to select the secondary
reference source. If the timecode source fails, the UDC/DTD will use the secondary
reference as the time source. You can select a secondary reference from one of the these
two options:
INTERNAL The UDC/DTD uses its internal crystal oscillator as the clock
reference source.
To select this option, set DIP switch 4 to the left position.
LINE The UDC/DTD uses the AC power line frequency as the clock reference
source.
To select this option, set DIP switch 4 to the right position.
5. Enabling Timecode Auxiliary Offset
Using DIP switch 3, you can enable a user-programmed auxiliary offset from the input
timecode user-bits. To use this option, the input timecode source must come from a
MTG-3901, CSD-3901/3902, or CSD-5300 clock system driver.
To enable the timecode auxiliary offset, set DIP switch 3 to right position. To disable the
timecode auxiliary offset, set DIP switch 3 to left position.
6. Setting LED and Date Display
Using DIP switch 2 you can select options for the LED and date display.
NORMAL When using the this setting, if the input timecode source fails, the
colon LEDs flash twice per second.
RUN ON SECONDARY When using this setting, if the input timecode source
fails, the colon LEDs stop flashing. If the timecode source is a MTG-3901,
CSD-3901/3902 or CSD5300, the UDC/DTD displays the date.
7. Setting 12 Hour or 24 Hour Display
Using DIP switch 1, you can set the UDC/DTD display to either 12 hour or 24 hour
display.
12 HOUR When in Clock mode, the clock displays time in A.M. and P.M time
convention. When the clock is in Timecode Reader mode and DIP Switch 2 is set to
the left position (NORMAL), the clock displays timecode as HH:MM:SS. When
the clock is in Timecode Reader mode and DIP Switch 2 is set to the right position
(date if code is present), the clock displays timecode as DD:MM:YY.
To select this option, set DIP switch 1 to the left position.
24 HOUR When in Clock mode, the clock displays time in 24 hour time
convention (00—23 hours). When the clock is in Timecode Reader mode and DIP
Switch 2 is set to the left position (NORMAL), the clock displays timecode as
MM:SS:FF. When the clock is in Timecode Reader mode and DIP Switch 2 is set to
the right position (date if code is present), the clock displays timecode as
MM:DD:YY.
To select this option, set DIP switch 1 to the right position.
