Failure to connect as shown in this diagram will damage this charger.
WARNING:
The main battery leads must be connected along with the balance lead connector as shown before charging
your battery ..
If using crocodile clips as shown in above diagram, make sure they are unable to touch
together!
WARNING:
LITHIUM POLYMER BALANCE CHARGE PROGRAM
CONNECTION DIAGRAM
LITHIUM POLYMER BALANCE CHARGE PROGRAM
CONNECTION DIAGRAM
This diagram shows the correct way to connect your battery to the B6charger while charging in
the balance charge program mode only.
06
