Nemo 96 HD+
Connection of Optional Modules
Turn off the meter
Connect th optional module
Feed the meter and wait some seconds for the module recognition
To program the parameters of each module, please refer to the relevant manual
3.0 Password 3002
Communication Protocole.
For the communication modules (see table) it is necessary to set the Communication
Protocol.
Load password 3002 and select the communiction protocol (See table).
*For details, please see the communication protocol.
IF96001
RS485
IF96002
RS232
IF96007A
PROFIBUS
IF96009
LonWorks
IF96012
Memoria
IF96013
M-Bus
IF96014
Bacnet
IF96015
Ethernet
PROTOCOL
MdbS
MtCP
MdbS
MtCP
MdbS
MtCP
MdbS
MtCP
MdbS
MtCP
Mbus*
Mb 2*
bACn
MdbS
MtCP
IF96018
Radio 868MHz
MdbS
MtCP
ATTENTION!
Module connection must be carried out with non-fed meter
