Nemo D4-e
07/17 10783591 WEB E cod.MFD4E06
2
Multimeasure
They measure
and display more
measurement units
at the same time
Energy counting
They quantify the
energy consumption
Communication
They communicate the
measurements carried
out remotely
They interface different
communication modes
Measuring and
monitoring
They measure
and report special
conditions
I.M.E. S.p.A. reserves the right to modify at any time the technical characteristics without notice.
The product technical documentation is available on the www.imeitaly.com site in the “Technical documentation” section, type in the following field “Technical Note Code: NT901”.
Index
Wiring diagrams page 3
Mounting instructions page 3
Programmaing page 4
Programmable parameters page 4-5
Phase sequence diagnostic page 5
Level 1
Password = 1000
1.0
Password page 4 and 6
1.1
Customised display page page 4 and 6
Customisable measurement tables page 7
1.2
Connection page 4 and 8
1.3
Average power and current integration time page 4 and 8
1.4
Hour-meter counting start page 4 and 8
1.5
RTU/TCP ModBus RS485 communication page 4 and 9
1.6
Energy pulses page 4 and 9
Level 2
Password = 2001
2.0
Password page 5 and 10
2.1
External CT ratio page 5 and 10
Display page 11
(3N-3E) three phase 4 wire configuration page 12
(3-3E / 3-2E) three phase 3 wire configuration page 13
(1N-1E) single phase configuration page 14
Auxiliary Supply page 15
Factory settings page 15
