IMER KOINE 35 - Page 23

23
KOINE 35
IMER U.S.A. Inc.
TAV. 1 MACHINE STRUCTURE
DA MATRICOLA
À PARTIR DU NUMÉRO DE SÉRIE
FROM SERIAL NUMBER
VON SERIENNUMMER
DEL NUMERO DE SERIE
Rif. Cod. DESCRIPTION Note
1 3223726 KOINE5 HOPPER
2 3225842 COMPRESSOR
3 3223422 RUBBER WHEEL D.200
4 3223366
DUST OUTLET DOOR
SEAL
5 3223378 PLUG
6 3223412 FRAME
7
1107084
STATOR
ECO STAR CB/63
KOINE 35
1107032
EOB/SM D4-1/2
KOINE 35 AEROBLUE
8 2224640 WASHER 6592
9 3223388 MANIFOLD
10 3223719 CLAMPING CONES
11 3223720 TIE-ROD
12 3223389 GUARD
13 3223703 M-M CAM COUPLING
14 3227962 GUARD
15 3229673 ELECTRICAL PANEL
16 3223370 MIXING CHAMBER
18 1107542 MIXER
3006583 19 3228425 FLANGED HOSE
20 3223352 TERMINAL
3006583 21 3228424 GUARD
22 3223716 HANDLE
23 3223374 CHAMBER PIN
3006583 24 3229688 MIXER GEARMOTOR
3006766 25 3229264 COVER
26 3228031 WATER CIRCUIT
3006766 27 3229325 LOC KING HANDLE
28 3223394 CELL WHEEL
29 3224139 RH GUARD
30 3223376 CENTRAL EYEBOLT
31 3223377 WHEEL SUPPORT
3006766 32 3230205 KOINE 5 MESH
33
34
1107085
CAM SCREW
ECO STAR
(KOINE 35)
1107033
EOB/SM D4-1/2
(KOINE35 AEROBLUE)
35 3223717 SAFETY HANDLE
36 3223421 BRAKE WHEEL D.200
37 3223354 PIPE WRENCH
38 3223347 VERTICAL SECTION
39 3223349 SCRAPER
40 3233856
CELL WHEEL
GEARMOTOR
41 3207209 FEMALE EYEBOLT M8 Z
42 3223397 CELL WHEEL TYRE
43 3223689
MANIFOLD PRESSURE
GAUGE
44 3223391 SPACER M8 F Z
45 3223392
ANTI-FREEZE
MEMBRANE
M8 Z
46 3223986 SCREW 8X50 TTCQ Z
47 3223987 SCREW 8X20 TTCQ Z
48 2226700 SPLIT PIN D.3.5 Z
49 3223724 GRILL
50 2222060 SCREW
T.E 8.8 5739
8X20 Z
51 2222156 SCREW
T.E 8.8 5737
10X50 Z
52 2223920 SELF LOCKING NUT M10 Z
53 3224142 SCREW
T.E 8.8 5739
8X45 Z
54 3223702 FLANGED NUT
M16
UNI 6923 Z
55 2222034 SCREW
T.E 8.8 5739
12X20 Z
56 2222088 SCREW
T.E 8.8 5737
8X40 Z
57 1222050 SCREW
T.E 8.8 5739
8X50 Z
58 1222047 SCREW
T.E 8.8 5739
8X70
59 2223570 NUT M16 Z
60 3224148 REAR APRON
61 3224149 FRONT APRON
62 3224150 REAR APRON SHEET
63 3224151 FRONT APRON SHEET
64 3223609 REDUCTION
M.1/2" F. 1/4"
65 3224173 REDUCTION
M.1" 1/2 F. 1/2"
66 3234104 TOOLBOX KIT
