IMER MORTARMAN 120 PLUS - Page 12

,0(5,17(51$7,21$/6S$
MORTARMAN 120 PLUS

1
2
3
4
5
6
7
8
9
10
11
12
13
7$9
75$160,66,21
5() &2'( '(6&5,37,21 127(6
1 2222420 BOLT AUTOF. TE 6950 D.4,8X13 Z
2 2222599 BOLT TSPEI 10.9 5933 M10 X16 Z
3 2224204 WASHER 6593 D.8X24 Z
4 2227310 STOP RING E 19
5 2229310 KEY 6X6X30
6 3226385 GEAR BOX
7 3227870 BOLT TRILOB. TEFR 5739 M8X16 Z
8 3229828 MOTOR
9 3229795 PULLEY
10 3229599 MOTOR SUPPORT
11 3229605 GUARD
12 3229609 BELT
13 3262752 BOLT TE 8.8 5737 M8X80 Z
