TAV.10.2 LANCIA SPRUZZARICE - LANCE DE PROJECTION - SRPAY JET - SPRÜHLANZE - PISTOLA ROCIADORA
Rif. Cod. I F GB D E Note
1 1107568 LANCIA SPRUZZATRICE LANCE DE PROJECTION SRPAY JET SPRÜHLANZE PISTOLA ROCIADORA
2
3225832
TUBO ARIA COMPLETO
PER LANCIA
TUYAU D'AIR COMPLET
POUR LANCE
COMPLETE AIR HOSE
FOR SPRAYER
LUFTSCHLAUCH
KOMPLETT FÜR
SPRITZGERÄT
MANGUERA AIRE COM-
PLETA PARA LANZA
3
3224818 ATTACCO RAPIDO
RACCORD EXCENTRI
UE
QUICK COUPLING SCHNELLKUPPLER CONEXIÓN RÁPIDA D.10
4 3224823
FASCETTA STRINGI-
TUBO
COLLIER CLAMP SCHELLE ABRAZADERA D.15-18
5 2292365 TUBO AIR WATER TUYAU HOSE SCHLAUCH MANGUERA D.10X16
6 3228354 PORTAGOMMA EMBOUT DE TUYAU AIR HOSE CLAMP SCHLAUCHHALTER NIPLES 3/8" M. x D.10
7 3223344 RACCORDO AD ANELLO
RACCORD AVEC
ANNEAU
FITTING WITH RING
ANSCHLUSSSTÜCK MIT
RING
UNION CON ANILLO 3/8"
8 3228353
NIPLES RIDOTTO
3/8"-1/4"
NIPLES REDUIT 3/8"-1/4"
REDUCED NIPPLE
3/8"-1/4"
NIPPLE REDUZIER-
STÜCK 3/8"-1/4"
NIPLE REDUCTOR
3/8"-1/4"
3/8"-1/4"
9 3227953 VALVOLA SFERA BOISSEAU SPHERIQUE BALL VALVE KUGELVENTIL VÁLVULA ESFERA 1/4" F.F.
10 3225186
NIPLES
CONICO-CONICO
NIPPLES
CONIQUE-CONIQUE
NIPPLES
TAPER-TAPER
NIPPEL
KEGEL-KEGEL
NIPLES
CÓNICO-CÓNICO
1/4"
11 3224968 RACCORDO "T" RACCORD COUPLING VERBINDDUNGSDTCK RACOR 1/4" F.F.F.
12 3224496 VALVOLA REGOLABILE VALVE REGLABLE VALVE ADJUSTABLE VENTIL JUSTIERBAR VÁLVULA AJUSTABLE 1/4" M.F.
13 3227955 PORTAGOMMA EMBOUT DE TUYAU AIR HOSE CLAMP SCHLAUCHHALTER NIPLES 1/4" M. x D.10
14 3227968 PORTAGOMMA EMBOUT DE TUYAU AIR HOSE CLAMP SCHLAUCHHALTER NIPLES 1/8" F. x D.10
15 3223350 TUBETTO ARIA ZINCATO TUYAU D'AIR AIR HOSE LUFTSCHLAUCH MANGUERA AIRE L.135
16 1107553 KIT N°5 DUSE D.14 KIT N°5 DUSE D.14 KIT N°5 DUSE D.14
KIT N°5 DUSE
D.14
KIT N°5 DUSE D.14 D.14
17 3223345
TESTA LANCIA SPRUZ-
ZATRICE
TETE DE LANCE DE
PROJECTION
SPRAYER HEAD
KOPF FÜR
SPRITZGERÄT
CABEZAL PARA LANZA
ROCIADORA
18
3209356 GOLFARE M10 VIS SCREW SCHRAUBE TORNILLO M.10
19 3223348
TUBO IN PLASTICA PER
LANCIA SPRUZZATRICE
TUYAU PLASTIQUE
POUR LANCE DE
PROJECTION
HOSE IN PLASTIC FOR
SPRAY JET
PLASTIKROHR F.
SPRÜHLANZE
TUBO DE PLÁSTICO
PARA PISTOLA ROCIA-
DORA
20
3225833 VALVOLA SFERA BOISSEAU SPHERIQUE BALL VALVE KUGELVENTIL VÁLVULA ESFERA 1" M.F.
21 3224701 ATTACCO A CAMME
RACCORD EXCENTRI-
QUE
CAM-LOCK COUPLING NOCKENANSCHLUSS RACOR TIPO CAMLOCK DN25 F. -1" G.F.
22 3224498 LEVA LEVIER LEVER HEBEL PALANCA DN 25-35-50
23 3224830
GUARNIZIONE ATTACCO
A CAMME DN 25
JOINT DE RACCORD À
CAMES DN 25
SEAL CAM COUPLING
DN 25
DICHTUNG F. NOCKE-
NANSCHLUSS DN 25
JUNTA RACOR TIPO
CAMLOCK DN 25
DN.25
24 3223697
GUARNIZIONE ATTACCO
RAPIDO
JOINT DE RACCORD
EXCENTRI UE
QUICK COUPLING
GASKET
DICHTUNG SCHNEL-
LKUPPLER
JUNTA CONEXIÓN
RÁPIDA
