Imesa ES23 - Page 5

E980702H 02/12/04
5
Tab.5 (GREAT BRITAIN)
Model
ES10
GAM
(TD10)
ES10
GAB
(TD10)
ES14
GAM
(TD14)
ES14
GAB
(TD14)
ES18
GAB
(TD18)
ES23
GAC
(TD23)
ES34
GAD
(TD34)
ES55
(TD55)
NATURAL GAS
2H (G20)
Low heating power 34.02 MJ/m
3
Nominal pressure 2000 Pa
Maximum pressure 2500 Pa
Minimum pressure 1700 Pa
Injectors Φ mm 1 x 2.90 2 x 2.90 1 x 2.90 2 x 2.90 2 x 2.90 3 x 2.70 4 x 2.70 3 x 4.0
Consumption m
3
/h 1.53 3.07 1.53 3.07 3.07 4.0 5.33 8.0
PROPANE GAS
3+ (G30)
Low heating power 45.65 MJ/Kg
Nominal pressure 2800 – 3000/3700 Pa
Maximum pressure 3500/4500 Pa
Minimum pressure 2000/2500 Pa
Injectors Φ mm 1 x 1.85 2 x 1.85 1 x 1.85 2 x 1.85 2 x 1.85 3 x 1.75 4 x 1.75 3 x 2.7
Consumption Kg/h 1.14 2.29 1.14 2.29 2.29 2.98 3.97 6.0
Type B22
Φ inner exhaust outlet (mm) 150 150 150 150 150 200 200 300
Outlet pipe maximum pressure 150 Pa
Tab.5 (IRELAND)
Model
ES10
GAM
(TD10)
ES10
GAB
(TD10)
ES14
GAM
(TD14)
ES14
GAB
(TD14)
ES18
GAB
(TD18)
ES23
GAC
(TD23)
ES34
GAD
(TD34)
ES55
(TD55)
NATURAL GAS
2H (G20)
Low heating power 34.02 MJ/m
3
Nominal pressure 2000 Pa
Maximum pressure 2500 Pa
Minimum pressure 1700 Pa
Injectors Φ mm 1 x 2.90 2 x 2.90 1 x 2.90 2 x 2.90 2 x 2.90 3 x 2.70 4 x 2.70 3 x 4.0
Consumption m
3
/h 1.53 3.07 1.53 3.07 3.07 4.0 5.33 8.0
PROPANE GAS
3+ (G30)
Low heating power 45.65 MJ/Kg
Nominal pressure 2800 – 3000/3700 Pa
Maximum pressure 3500/4500 Pa
Minimum pressure 2000/2500 Pa
Injectors Φ mm 1 x 1.85 2 x 1.85 1 x 1.85 2 x 1.85 2 x 1.85 3 x 1.75 4 x 1.75 3 x 2.7
Consumption Kg/h 1.14 2.29 1.14 2.29 2.29 2.98 3.97 6.0
Type B22
Φ inner exhaust outlet (mm) 150 150 150 150 150 200 200 300
Outlet pipe maximum pressure 150 Pa
