5. Calibration & Level Checking
The accuracy of the tool is +/- 1.5mm in 10m.
Before use, check that the instrument is within tolerance.
-Place instrument on a solid base i.e. bench top, approx 5m from a wall.
-Turn on horizontal beam and vertical beams
-To check horizontal beam, point cross-line towards wall & mark the wall at horizontal
level point
-Rotate instrument on tripodic base towards the left end of horizontal beam and mark
wall again, repeat this procedure at the right end of the horizontal beam
-You should now have three marks on the wall. If these points are less than
1.5mm apart the instrument is ok to use if difference exceeds 1.5mm send back to
dealer for calibration.
To check vertical accuracy, utilise a known plumb point such as a doorway/window
frame and check that vertical beam lines up.
6. Transportation and Storage
The laser must be stored in a cool dry environment, free of dust and moisture.
On the completion of use the main On/Off switch must be switched to the off position
for transportation.
7. Warranty
The Imex LX33G are covered by a 2 year warranty for more details please visit:
www.imexlasers.com.au
8. Accessories
The LX33 can be used with a number of accessories, these include;
-Elevating tripod -Wall mount bracket
-Floor–ceiling laser pole -Levelling staff & more
9. Specifications
