Mount the Doorbell on Surfaces Made Out of Hard Materials
1.If you‘re mounting the doorbell on a surface made out of hard materials, like brick,
concrete, stucco, drill 2 holes through the Screw Hole Positioning Card with a 15/64”
(6mm) drill bit.
2.Insert the provided anchors,and then use provided long screws to secure the Mounting
Bracket on the wall.
What is required: Power Drill, 15/64”(6mm) Drill Bit, Mounting Bracket, 15° Mounting
Wedge , Mounting Screws andAnchors.
Power Drill
(not provided)
15/64”(6mm)
Drill Bit
Mounting Bracket 15° Mounting
Wedge
Mounting Screws
and Anchors
1
Wall Mounting
Bracket
Without 15° Mounting wedge
Wall Mounting
Bracket
Mounting
Wedge
With 15° Mounting wedge
2
To Next Page
