Place the Screw Hole Positioning Card against the wall to mark the position.
Mount the Doorbell on a Wooden Surface
If you’re mounting the doorbell on a wooden surface, you don’t need to pre-drill pilot
holes. Use the provided screws to secure the Mounting Bracket on the wall, The Screw Hole
Positioning Card indicates the position of the screw holes. What is required: Screwdriver,
Mounting Bracket, 15
° Mounting Wedge , Mounting Screws and Anchors.
Screwdriver
(not provided)
Mounting Bracket 15° Mounting
Wedge
Mounting Screws
and Anchors
Wall Mounting
Bracket
Without 15° Mounting wedge
Wall Mounting
Bracket
Mounting
Wedge
With 15° Mounting wedge
