NOTE : To restart the wizard
at any time, power up the
quad, and press, and hold,
the button on the LED board
for approx. 8 seconds.
Once the wizard is finished,
various Cleanflight settings
will be configured, including
enabling oneshot,
motor_stop, and failsafe.
Another setting which is automatically made is the assignment of CH5 to the flight mode,
Acro, Horiz, and Angle. To complete the setup, configure your R/C Tx to link CH5 to a
3-position switch.
Ensure that the switch correctly switches between the three flight modes, reflected in the
top-right corner of the OSD main landscape .
Note that It is highly recommended to attempt the maiden flight in either Angle, or Horiz
mode. Acro takes a little getting used to.
NOTE: Even though the flight controller failsafe has been set by the wizard, it is important
to also set the R/C Rx failsafe.
On the EzUHF this is as easy as setting the controls in a ‘safe’ position (very low throttle
for example) and holding down the bind button on the EzUHF Tx until a beep is heard.
Flyaways with mini-quads are almost always caused by incorrect failsafe settings!
NOTE: Currently there is no ‘servo reverse’ feature in Cleanflight. This means that if one of
the R/C transmitter channels is reversed, the wizard will not complete correctly.
It is highly recommended to start the wizard with a ‘new’ profile in the R/C radio, without
any channel reversing, and also without any expo. Expo is all handled within the
Pro-Tuning profiles.
