ImmersionRC Vortex - ESC and Receiver Specs; Performance and Dimensions

ESC
Type
ImmersionRC EzESC
Rating
12A continuous, 16A peak
Features
OneShot125, and Motor Braking
Processor
32-bit ARM
R/C Receiver
Channels Required
Absolute minimum four. Five recommended to support mode switch.
Interface Standard
3.3v-5v PPM Sum (all channels in one PPM stream)
Receiver Power
+5v @ 200mA max. (3.3v supplied using the optional Spektrum Rx cable)
Flight Characteristics
Flight Time
Depends upon battery, and flight style
Maximum Range
Highly dependent on battery, and flying style
Maximum Speed
TBD
Blackbox Support
Compatibility
Supported via the GPS port on the Vortex PDB, Instructions to follow
Camera Support
Onboard GoPro Supply
+5v at 1A
Video Standard
Composite, PAL or NTSC, switchable using a camera-mounted jumper
Weight and Size
Weight, as Shipped, ARF
~350g
Weight, Typical RTF
497g w/1300mAh 45C 4s pack
Size
283mm between diagonal motors
Folded Size
300 X 110mm
