Impax IM2800IFG - Component Identification - Page 3; Fuel Cap and Gauge Location; Tools and Accessories; Technical Specifications

9
COMPONENTS
20
19
22
21
Component List
19. Fuel cap
20. Fuel gauge
21. Screwdriver
22. Spark plug socket
23. Funnel
24. DC charging leads
AC output: 230V~50Hz
Rated power: 2800W
Peak power: 3000W
Rated current: 12.17A
Phase: Single
Power factor: cosø=1
Displacement: 212cc
DC output: 12V, 8A
Engine: 4 stroke, OHV
No load speed (low): 2800min
-1
No load speed (high): 3300min
-1
Rated load speed: 3600min
-1
Continuous operating time: 10hrs (70% load)
Fuel tank capacity: 13L
Fuel type: Unleaded petrol
Oil type: SAE 10W-30
Oil capacity: 460ml
Ignition system: C.D.I.
Starting system: Recoil starter
Spark plug type: F7RTC
Net weight: 34kg
Protection: IP23M
Perfomance class: G1
Max. temperature: 40ºC
Max. altitude: 1000m
Quality class: A
Sound power level (7m away): 68dB(A)
TECHNICAL SPECIFICATION
23
24
