Impex MARCY CLASSIC MCB-252 - Parts List

PARTS LIST
KEY NO. DESCRIPTION QUANTITY
1 Rear Upright Beam 2
2 Cross Brace 1
3 Main Seat Support 1
4 Diagonal Support 1
5 Front Stabilizer 1
6 Bracket 1
7 Grip 2
8 Backrest Adjustment Bar 1
9 Leg Developer 1
10 Foam Tube 2
11 Weight Holder 1
12 Lat Bar Frame 1
13 Lat Bar 1
14 Backrest Support 2
15 Arm Curl Stand 1
16 Weight Storage Post 2
17 Backrest Board 1
18 Seat Pad 1
19 Arm Curl Pad 1
20 Weight Bar 1
21 10 lbs Weight Plate 4
22 1” x 2” End Cap 6
23 1 ¼” End Cap 2
24 1 ½” End Cap 4
25 Ø ¾” End Cap 4
26 Ø 1” End Cap 4
27 M6 x 1 ¼” Hex Bolt 4
28 Ø 1” Weight Post End Cap 5
29 Pulley Bushing 2
30 Pulley 1
31 Sleeve 3
32 Hook 2
33 Cable 1
34 Leg Developer Spacer 2
35 Foam Roll 4
36 Spring Clip 5
37 Lock Knob 1
38
M10 x 2 ¾” Hex Bolt 5
39 M10 x 2 1/8” Hex Bolt 2
40 M10 x 2” Hex Bolt 1
41 M8 x ¾” Hex Bolt 6
42 M8 x 2 1/8” Hex Bolt 1
43 M6 x 1 ½” Hex Bolt 4
44 Ø ¾” Washer 7
45
Ø 5/8” Washer 7
46 Ø ½” Washer 8
47 M10 Aircraft Nut 8
48 M8 Aircraft Nut 1
49 1” Square End Cap 2
50 25 lbs Weight Plate 2
51 15 lbs Weight Plate 2
11
