Impulse AC2990 User Manual

─ 19 ─
Parts List and Exploded View
Console ASSY
ItemNo.
Grade No. Part No. Description QTY
1 2.1 AC29905000 Front Cover of Console 1
2 2.2 ECT74800 Buffer Pad For Key 21
3 2.3 B242 Main PCB 1
4 2.4 GB845ST2.9*9.5DS Phillip Screw ST2.9*9.5 21
5 2.5 AC29900200 Bracket for Console 1
6 2.6 GB845ST4.2*13DS Phillip Screw ST4.2*13 8
7 2.7 GB6560M4*8DSG Phillip Screw M4*8 1
8 2.8 GB862.24DS12 Serrated lock washers Φ4 1
9 2.9 AC29905100 Back Cover of Console 1
10 2.10 GB818M4*10DHS2 Phillip Screw M4*10 7
11 2.11 AC2990MM01 Console Key Overlay 1
12 2.12 AC2990MM02 Console Warning Overlay 1
13 2.13 L300M43025-25-9JD Console Wire Up 1
14 2.14 L300M43020-25-2 Extended Wire For Emergency Switch 1
15 2.15 L350M35155-84-2 Extended Wire For Pulse Connect Wire 1
16 2.16 DQCH01-SBD Ferrite 1
17 2.17 DQCH02-SBD Ferrite 1
18 2.18 SD4*150 Band Cable 4
19 2.19 SDZ21 Band Cable Holder 4
20 2.20 LD2000 Protective Sleeve 1
21 2.21 DQXTJS02 Receptor 1
22 2.22 RU5004400 The Receiver Cover 1
23 2.23 CRDMJ20*1 Double Sided Adhesive 1
