Impulse AC2990 User Manual

─ 23 ─
Parts List and Exploded View
Mainframe Assembly
ItemNo. Grade No. Part No. Description QTY
1 5.1 AC299003-22ASSY
Deck Frame and Inverter Frame Assembly
1
2 5.2 AC29900801 Front Bracket for fixing Motor Cover 3
3 5.3 AC32705800 Clip Nut M6 4
4 5.4 GB70M6*15DHS4 Socket Head Cap Screw M6*15 4
5 5.5 ECU7P3500 Plastic Clip Block 3
6 5.6 GB845ST4.2*16DS Phillip Screw ST4.2*16 3
7 5.7 GB9074ST4.2*16DHS Big head Phillip Screw ST4.2*16 23
8 5.8 AC32701801 Dust Proof Plate 1
9 5.9 GB818M5*15DHS2 Phillip Screw M5*15 22
10 5.10 GB17880.3M5*13DS17 Countersunk head hexagon riveted n uts M5 20
11 5.11 AC29900900 Left Front Deco Bracket 1
12 5.12 AC29901000 Right Front Deco Bracket 1
13 5.13 PT3005000 Side Bracket for fixing Motor Cover 2
14 5.14 DC29500900V1 Left Rear Support 1
15 5.15 DC29501000V1 Right Rear Support 1
16 5.16 AC29901200 Deck 1
17 5.17 AC29901100 Side Rail 2
18 5.18 HT95T5300A Dish Gasket 16
19 5.19 GB845ST4.2*13DS Phillip Screw ST4.2*13 16
20 5.20 AC2970H2200 Front Roller 1
21 5.21 AC29702300 Rear Roller 1
22 5.22 GB70M10*55*55DHS2 Socket Head Cap Screw M10*55 1
23 5.23 DQ10DS2A Washer Φ11*Φ23*2 1
24 5.24 GB70M10*80*80DHS20 Socket Head Cap Screw M10*80 2
25 5.25 AC2970S1800V1 Running Belt 1
26 5.26 DXD250J10A V-Belt 1
27 5.27 PT3002800P294U Bumper A 4
28 5.28 PT3002900P294U Bumper B 4
29 5.29 AC32700636 Washer Φ30*Φ9*3 4
30 5.30 STDP6800 Locknut M8 13
31 5.31 CNLM8*40DS20
Hexagon s ocket countersunk head c ap head screw M8*40
8
32 5.32 GB17880.3M8*16.5DS17
Countersunk head hexagon riveted n uts M8
4
33 5.33 DC29503200 Bumper 2
34 5.34 AC299013ASSY Motor Assembly 1
35 5.35 GB70M8*95DHS20 Socket Head Cap Screw M8*95 1
36 5.36 DQ8DHS2A Washer Φ9*Φ22*2 1
37 5.37 GB958DHS2 Washer Φ9*Φ16*1.6 4
