Impulse ES2100 - Page 13

─ 13 ─
Exploded View and Parts List
Guide Bar Fixed Seat ASSY Olympic Bar ASSY
ItemNo.
Grade No. Part No. Description QTY
1 10.1 ES20001700 Guide Bar Fixed Seat 1
2 10.2 KPSHCS2700 Rubber Sleeve 1
ItemNo.
Grade No. Part No. Description QTY
1 11.1 ES20002700 Olympic Bar 1
2 11.2 GB894.128FH12 Circlip for Sharf 2
