Impulse ES2100 - Page 19

─ 19 ─
Exploded View and Parts List
Right Safety Catch
ASSY
ItemNo.
Grade No. Part No. Description QTY
1 21.1 ES20001400ASSY Safety Catch ASSY 1
2 21.2 ES20001600ASSY Right Safety Hook ASSY 1
3 21.3 GB5780M12*65DS20 Hex Head Bolt M12*65 1
4 21.4 GB9512DS2 Flat Washerφ13*φ24*2.5 2
5 21.5 NM12DS2 Nylon Lock Nut M12 1
ItemNo.
Grade No. Part No. Description QTY
1 21.2.1 ES20001600 Right Safety Hook 1
2 21.2.2 M01402000 Bushing 2
3 21.2.3 CG50001700 Grip 1
Right Safety Hook
ASSY
