Impulse ES2100 - Page 21

─ 21 ─
Exploded View and Parts List
Pulley Frame ASSY
ItemNo.
Grade No. Part No. Description QTY
1 21.1.1 ES20001400 Safety Catch 1
2 21.1.2 ES20003400 Nylon Bushing 2
Safety Catch ASSY
ItemN o.
Grade No. Part No. Description QTY
1 23.1 ES20001800 Pulley Frame 1
2 23.2 M01004800V7 3.5" Pulley 1
3 23.3 HF900-03A1002 Hex Flanged Nut 1/2″-13 2
4 23.4 GB5780M10*45DS20 Hex Head Bolt M10*45 1
5 23.5 GB9510DS2 Flat Washer Φ11*Φ20*2 2
6 23.6 NM10DS2 Nylon Lock Nut M10 1
