Impulse ES2100 - Page 23

─ 23 ─
Exploded View and Parts List
Left Safety Frame
ASSY
Right Safety Frame
ASSY
ItemNo.
Grade No. Part No. Description QTY
1 26.1 ES20002300 Left Safety Frame 1
2 26.2 KFHC2200 Long Plastic Plate 1
3 26.3 CNLM6*12DHS20NL
Hexagon socke t counte rsunk head screwsM 6*12
3
ItemNo.
Grade No. Part No. Description QTY
1 27.1 ES20002400 Right Safety Frame 1
2 27.2 KFHC2200 Long Plastic Plate 1
3 27.3 CNLM6*12DHS20NL
Hexagon socke t counte rsunk head screwsM 6*12
3
