Impulse RT700 User Manual

─ 14 ─
Parts List and Exploded View
Installation Instructions
Item No. Grade No.
Part No. Description QTY
1 1 RT700H01ASSY Console Frame Assembly 1
2 2 RT7000200 Left Upright 1
3 3 RT7000300 Right Upright 1
4 4 RT700K04-22WXASSY Mainframe 1
5 4.35 RT7002000 Motor Cover 1
6 4.50 GB70M6*20DHS20 Socket Head Cap Screw M6*20 24
7 7 RT700HDZBASSY Console Component 1
8 8 RT7004300 Left Routing Cover 1
9 9 RT7004400 Right Routing Cover 1
10 10 RT7004500 Left Bolt Cover 1
11 11 RT7004600 Right Bolt Cover 1
12 12 RT7006400 Console Back Cover 1
13 13 A01-6 Power Cable 1
14 14 AC2970C1100 Power Cable Fixing Plate 1
15 17.1 GB818M5*15DHS20 Phillip Screw M5*15 2
16 17.2 GB818M5*20DS2 Phillip Screw M5*20 4
17 4.54 GB5780M10*165*40DS20 Hex Head Bolt M10*165 2
18 4.56 GB5780M10*180DHS2 Hex Head Bolt M10*180 2
19 4.61 L1600JD-SM-XHB-10 Console Wire Down 1
20 1.31 L900JD-SM-VHR-10 Console Wire Up 1
21 1.29 B108 Switch Pcb 1
22 17.3 GB70JCM8*25DS20
Socket Head Cap Screw w/ Serrated lock
washer M8*20
8
23 7.6 L260VHR-SMA-2 12 Voltage Power Wire 1
24 17.4 GB9074.16M10*25DS20
Hex Head Bolt w/ Serrated lock washer
M10*25
4
25 17.5 GB818M4*10DHS2 Phillip Screw M4*10 2
26 17.6 DQ10DS2A Washer
Φ
11*
Φ
23*2 2
27 7.7 L260XHB-SMA-4 Joint Wire 1 1
28 7.8 L300XHB-SMA-12 Joint Wire 3 1
29 17.7 NM10DS2 Locknut M10 2
30 7.5 L190XHB-SMA-7 Joint Wire 2 1
