Impulse RT700 User Manual

─ 21 ─
Parts List and Exploded View
Mainframe
Item No. Grade No.
Part No. Description QTY
37 4.37 STDP6800 Locknut M8 12
38 4.38 GB17880.5M6*16.5DS17 Flat head hexagon riveted nuts M6 18
39 4.39 GB17880.3M6*15DS17 Countersunk head hexagon riveted nuts M6 2
40 4.40 NM8DS2 Locknut M8 1
41 4.41 GB845ST4.2*13DS Phillip Screw ST4.2*13 4
42 4.42 CNLM8*35DHS20NL
Hexagon socket countersunk head cap head screw M8*35
10
43 4.43 GB70M8*60*60DHS20 Hexalobular socket pan head tapping screw M8*60 1
44 4.44 DQ8DS2A Washer Φ9*Φ22*2 7
45 4.45 GB70M8*80*80DHS6 Socket Head Cap Screw M8*80 2
46 4.46 GB5780M8*30DS20NL Hex Head Bolt M8*30 4
47 4.47 GB818M5*20DS2 Phillip Screw M5*20 4
48 4.48 GB818M5*15DS2 Phillip Screw M5*15 8
49 4.49 DQCH01-SBD Ferrite 1
50 4.50 GB70M6*20DHS20 Socket Head Cap Screw M6*20 24
51 4.51 GB5780M8*150DS2 Hex Head Bolt M8*150 6
52 4.52 GB70M6*30DS4 Phillip Screw M6*30 6
53 4.53 GB70M6*45DS4 Socket Head Cap Screw M6*60 2
54 4.54 GB5780M10*165*40DS20 Hex Head Bolt M10*165 2
55 4.55 DQ10DS2A
Washer Φ11*Φ23*2
6
56 4.56 GB5780M10*180DHS2 Hex Head Bolt M10*180 2
57 4.57 GB6560M4*8DSG Phillip Screw M4*8 3
58 4.58 GB862.24DS12 Serrated lock washers
Φ
4 3
59 4.59 DQXX0110.4 U-shape Wires Clip 2
60 4.60 L250AMP175022-1-N-14 Connect wire 2
61 4.61 L1600JD-SM-XHB-10 Console Wire Down 1
62 4.62 LD2000 Protective Sleeve 1
63 4.63 SD3*150 Band Cable 5
64 4.64 GB41M10DS2 Nut M10 4
65 4.65 DQCH02-SBD Ferrite 1
66 4.66 RT7001800 U-shape bracket 1
67 4.67 SDZ21 Band Cable holder 5
68 4.68 CHP-2 wire holder 4
69 4.69 T15856.1ST4.2*16DHS Phillip Screw ST4.2*13 17
70 4.70 GB938DHS12 Spring washer 1
71 4.71 DQDT0710 Heat Shrink Tubing 0.01
