Impulse RT700 User Manual

─ 24 ─
Parts List and Exploded View
A-ZONE Up Cover Assembly
Item No.
Grade No. Part No. Description QTY
1 1.43.1 RT7005400V1 A-ZONE Up Cover 1
2 1.43.2 RT7006300 A-ZONE Insert 1
3 1.43.3 RT7005700 Fan Key 2
4 1.43.4 RT7005800 COOL DOWN\PAUSE Key 2
5 1.43.5 F30 Key PCB 1
6 1.43.6 GB845ST2.9*6.5DS Phillip Screw ST2.9*6.5 9
7 1.43.7 GB845ST2.9*9.5DS Phillip Screw ST2.9*9.5 4
8 1.43.8 RT7006100 Air Grid 1
9 1.43.9 RT7006200 Air Up Cover 1
10 1.43.10 RT7005600 Emergency Switch Key 1
11 1.43.11 PT3002400 Reposition Rack 1
12 1.43.12 PT3002500 Restrict Spring 2
13 1.43.13 RT7005900 Limit Key Fixing Plate 1
14 1.43.14 F10 Emergency Switch 1
15 1.43.15 RT7006000 Emergency Switch Baffle 1
16 1.43.16 GB8964FH12 Split damping ring Φ9 1
17 1.43.17 GT3003600 Nylon Shaft 1
18 1.43.18 GB845ST4.2*13DS Phillip Screw ST4.2*13 4
19 1.43.19 L600ST0/XHP-2 Emergency Switch Wire 1
21 1.43.21 RT500MM02 A ZONE Up Overlay 1
22 1.43.22 RT700MM02 A ZONE Down Overlay 1
23 1.43.23 STDP4012 Safe Key Clamp 1
24 1.43.24 F86 Emergency Switch 1
25 1.43.25 GT3003100 Switch holder 1

Impulse RT700 Specifications

General

Brand	Impulse
Model	RT700
Category	Treadmill
Language	English
