PAGE 7
Figure 3- Control panel
1. On/O button: switches the dishwasher On and O.
2. Program button: Press this button to cycle through the program options (i.e. Intensive, Glass, Eco, etc)
3. Intensive Program indicator: LED indicates whether this program is selected or not.
4. ECO Program indicator: LED indicates whether this program is selected or not.
5. 90 Min Program indicator: LED indicates whether this program is selected or not.
6. Rapid Program indicator: LED indicates whether this program is selected or not.
7. Rinse Aid indicator: Indicates when the rinse aid is low and that the dispenser needs to be refilled.
8. Program Ended indicator: Indicates when the dishwasher program has been completed.
9. Water Supply indicator: Indicates when the water supply tap is closed and needs to be turned on.
10. 3h/6h/9h Delay Start indicators
11. Delay button: Press the button to set a delayed start time.
12. Extra Drying function button: this activates the Extra Drying function.
This can only be used with the Intensive, ECO and 90 Min wash programs.
13. Child lock function: Simultaneously press the Delay and Half-load buttons to activate child lock.
14. Child lock indicator: LED indicates whether the child lock function is activated or not.
15. Extra Drying function indicator: LED indicates whether the Extra Drying function is activated or not.
16. Start/Pause button: Press this button to start the selected washing program or pause the washing program
when running.
Control Panel
15
10 11 12
13
163 5 7 9
4 86
14
1 2
