Indel GIN-SAM4 - Default Chapter; Table of Contents

Page 3 of 17
18.04.2019
Rev. 1.03
Table of Contents
1. General 4
1.1. About this manual 4
1.2. Sales and Service 4
1.2.1. Manufacturer 4
1.3. Copyright 4
1.4. Revisions 5
1.5. Terms 5
2. ProductIdentication 6
2.1. Accessories 6
2.2. Scopeofdelivery 6
2.2.1. GIN-SAM4 6
2.3. Label 6
2.3.1. GIN-SAM4,withadditionalinformationlikeserialnumber. 6
3. Technical Description 7
3.1. Rotary- Switch 7
3.2. Mounting 7
3.2.1. Box mounting 7
3.2.2. Shielded lines 7
3.2.3. Grounding 7
3.2.4. Shielding plate 8
3.3. Caution, laptop users 8
4. TechnicalSpecicationsGIN-SAM4 9
4.1. General 9
4.2. PowerSupply 9
4.3. Environmental Conditions 10
5. Pinout GIN-SAM4 11
5.1. Power Supply, on top 11
6. Connectors 12
6.1. ConnectorsEnclosureFront/Top 12
6.1.4.1. ConnectorsEnclosureBottom 13
6.2. ConnectorTopDetail(PowerSupply) 13
7. InternalExpansion(max.possibilities) 14
8. Mechanical Drawings 15
8.1. Mechanical Dimensions GIN-SAM4 15
