Technical Description
3. Technical Description
The GIN-SAM4 is a high-performance eldbus master board by Indel. The powerful master is
perfectly suited for high-speed applications with complex and high technical requirements.
As a eldbus master for the Indel GinLink, the GIN-SAM4 can control and coordinate the entire
peripheral equipment of a machine with a closed-loop bus frequency of up to 64kHz.
3.1. Rotary- Switch
With the help of the rotary switch certain basic modes of operation can be selected. Do newest
information can always be found in the Wiki.
Rotary Switch
Position
Emergency System Default
IP
Description
0x0 not used
0x1 not used
0x2 not used
0x3 not used
0x4 not used
0x5 ⅹ Emergency system
0x6
ⅹ Application with default IP
(192.168.1.251)
0x7 ⅹ ⅹ Emergency system with default IP
0x8 ... 0xF not used
3.2. Mounting
3.2.1. Box mounting
The standalone box will be mounted on a grounded wall with two M5 screws. You have to ensu-
re adequate air circulation for cooling.
3.2.2. Shielded lines
It is essential to operate the RS232 interfaces with shielded leads. The shielding must be con-
nected inside the connector at both ends.The RS422 interface can be operated with twisted pair
wires. For short distances, an unshielded cable will sufce. For RS422 connections over long
distances (>400m), it is advisable to use a shielded twisted pair cable.
3.2.3. Grounding
The GIN-SAM4 board is grounded via its front panel. Make sure that the connection between
the rack housing and the control cabinet is conductive (EMC grounding). This is best achieved
using chromatized mounting bars. The box is grounded via the conductive backplane.
