14
Operation
GB
Controls
B - Motor switch
Activates/deactivates the motor at the various speeds.
Position 0: motor deactivated.
Position I: motor running at 1st speed.
Position 2: motor running at 2nd speed.
Position 3: motor running at 3rd speed.
A - Light switch
Turns the lights on/off.
Position 0: light OFF
Position I: light ON.
C - Motor operational light
Ducting version operation
This hood is intended for installation in the ducting
version.
The hood aspirates air from the kitchen impregnated
with fumes and smells, passes it through the grease
filters and then expels it to the outside through an
exhaust duct.
A
BC
