COOKER DESCRIPTION
F Safety Device - Activates if the flame accidentally goes
out (spills, drafts, etc.), interrupting the delivery of gas
to the burner.
H Electric oven selector knob (cooking function
selection)
N Electric oven thermostat knob (temperature
selection)
A Auxiliary gas burner
B Semi-rapid gas burner
D Triple ring gas burner
C Rapid
M Control Knobs for Gas Burners
G Support Grid
S Electric oven operation indicator light
P Ignition Pushbutton for gas burners
E Ignitor for Gas Burners
R Pan reducing support
T Timer knob
E
F
