GB
5
the mains electricity supply A 13.
To connect directly to the mains supply, a double-
pole switch with a contact separation of at least 3
mm suitable for the load and complying with current
standards and regulations, must be fitted between
the appliance and the mains supply outlet. The
yellow-green earth wire must not be interrupted by
the switch. The supply cable must be in such a
position that no part of it can reach a temperature of
50 °C above room temperature. Do not use adapters
or shunts as they could cause heating or burning.
Before connecting to the power supply, make sure
that:
the limiter valve and the domestic system can
withstand the load from the appliance (see rating
plate);
the supply system is efficiently earthed according
to standards and laws in force;
the socket or double-pole switch are easily
accessible when the appliance is installed.
FAILURE TO OBSERVE THE ACCIDENT-
PREVENTION REGULATIONS RELIEVES THE
MANUFACTURER OF ALL LIABILITY.
Important: the wires in the mains lead are coloured
in accordance with the following code:
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the wires in the mains lead may
not correspond with the coloured markings
identifying the terminals in your plug, proceed as
follows:
Connect the Green & Yellow wire to terminal marked
Eor
or coloured Green or Green & Yellow.
Connect the Brown wire to the terminal marked Lor
coloured Red.
Connect the Blue wire to the terminal marked Nor
coloured Black.
Post Installation Checks
Perform post installation checks and ensure proper
and safe operation before leaving. Test all burners
individually and in combination.
Leak Check
Ensure all gas control knobs are in the Off
position.
Ensure the gas supply is switched on.
Spray a solution of soapy water onto all gas joints
as well as the full length of any flexible hoses.
UNDER NO CIRCUMSTANCES USE A NAKED
FLAME IN CHECKING FOR LEAKS.
If bubbles appear anywhere, turn the gas supply off,
check all connections and retest. If satisfactory
operation cannot be achieved, contact place of
purchase or their appointed agent for service.
Flame check
Turn each burner on, and ensure that the flame is
blue with minimal yellow tipping. If there is
significant yellow tipping, flame lift off or excessive
noise, check pressure and adjust at the regulator if
necessary.
If satisfactory operation cannot be achieved, contact
place of purchase or their appointed agent for
service.
Igniter operation
Check that the igniter for each burner successfully
ignites the gas.
If an igniter fails to work, first remove the plug from
the electrical power outlet, and then check that all
the electrical connections are in place.
If satisfactory operation cannot be achieved, contact
place of purchase or their appointed agent for
service.
Low flame setting
Check the low flame setting for each hob burner to
ensure that the minimum flame will not be
extinguished by air draughts.
Light the burner.
Turn the control until it engages in the minimum
position.
Ensure the flame is stable and will not be
extinguished by air draughts.
To adjust the minimum flame:
Follow the procedure described in the gas
conversion instruction.
DO NOT MODIFY THIS APPLIANCE IN ANY WAY,
OTHER THAN AS DESCRIBED IN THESE
INSTRUCTIONS.
Disconnecting the cable
Ensure that the means for disconnection of the
power cable is incorporated intot he fixed wiring in
accordance with local wiring rules.
(New Zealand statutory warning): The cooker must
be connected to the electricity supply by a cable
fitted with an appropriately rated plug that is
compatible with the socket-outlet fitted to the final
subcircuit in the fixed wiring that is intended to
supply this cooker.
Replacing the cable
Use a rubber cable of the type H05VV-F with a
suitable cross section 3 x 1.5 mm².
The yellow-green earth wire must be 2-3 cm longer
than the other wires.
