TECHNICAL SPECIFICATIONS
Gas Consumption
Natural Gas (1.0 kPa) ULPG (2.75 kPa)
Injector
Diameter
Gas Input
Injector
Diameter
Gas Input
Auxiliary Burner A 0.80 mm 3.3 MJ/hr 0.50 mm 3.5 MJ/hr
Semi Rapid Burner B 1.10 mm 6.0 MJ/hr 0.64 mm 5.5 MJ/hr
Rapid Burner C 1.29 mm 8.3 MJ/hr
0.80 mm 9.0 MJ/hr
Triple Ring Burner D 1.75 mm 15.0 MJ/hr 1.05 mm 15.0 MJ/hr
Total 38.6 MJ/hr 38.5 MJ/hr
Connections
Gas Inlet fitting 1/2 BSP (male) thread
Location of gas inlet Bottom rear of upright cooker
90 mm C/L from RH side (as viewed from front)
600 mm from base of upright cooker
Electrical input Flexible cord and earthed 10 Amp 3 pin plug
Location of Electrical Connection Rear of upright cooker
90 mm C/L from left hand side (as viewed from
front)
90 mm from base (without legs installed)
