Indesit Company
Service Manual UK English
TECHNICAL INFORMATION
Models Covered SIXL125SEU - Field Trial Machine
SIXL145UK, SIXL145SUK, SIXL145DUK, SIXL145DUK.1,
SIXL145KUK, SIXL145SKUK
Colours SIXL125SEU - Metallic Grey (Blue Door / Handle)
SIXL145UK - White (Metallic Grey Door / Handle)
SIXL145SUK - Metallic Grey (Blue Door / Handle)
SIXL145DUK - Metallic Grey (Grey Door / Handle)
SIXL145DUK.1 - Metallic Grey (Grey Door / Handle)
SIXL145KUK - White (Black Door / Handle)
SIXL145SKUK - Metallic Grey (Black Door / Handle)
Country of Origin Italy - Comunanza Factory (80)
Dimensions Height: 850 mm
Width: 595 mm
Depth: 535 mm
Weight - Net: 66 kg
Spin Speed 1400 rpm, except SIXL125SEU - 1200 rpm
Electrical Supply 220/240 Volts @ 50 Hz
Energy Consumption 1.02 kWh @ 60°C
Maximum Power Consumption 1850W
Energy Structure Energy Class: A+
Wash Class: A
Spin Class: B
Water Consumption (60°C Cotton) 65 litres
Water remaining after Spin Cycle 52%
Features Full Wash 6 kg, Cotton Whites, Mixed Coloureds, Delicates,
Rapid 30 minute / Rinse only
Wash Heater 1700W @ 230V - 30 Ω approximately.
Water Supply Cold Fill Only. Max Pressure = 1 Mpa (10bar)
Minimum Pressure = 0.05 Mpa (0.5bar)
Drum Capacity Load size: 1 - 6 kg. Drum Volume: 52 litres. Material: Plastic.
Motor - Wash Single phase (52 mm stator)
Ceset P52 / 1400rpm - MCA 52/64.148/AD40.
Armature: 2.15 Ω @ 20°C ± 7%
Field Coil: 1.47 Ω @ 20°C ± 7%
Split Field: 0.66 Ω @ 20°C ± 7%
Tacho: 115.4 Ω @ 20°C ± 7%
Pump 2 Pole Synchronous. 220 / 240 Volt 25 Watt, Resistance = 165 Ω
Max Head 1.4 metres. Flow rate @ 0.9 metres / 30 Litres per minute
Torque Settings
Front Counterweight 30 ± 2Nm (Torx 40 bolt)
Top Counterweight 30 ± 2Nm
Pulley 35 - 40 Nm
