Indesit UI8F1CW - Installation; Installing Single Appliance; Installing Two Appliances; Adjust Doors (If Available)

184


Toguaranteeadequateventilation,leaveaspaceon
both sides and above the appliance.
Thedistancebetweentherearoftheapplianceandthe
wallbehindtheapplianceshouldbeatleast50mm.
AreductionofthisspacewillincreasetheEnergy
consumption of product.

During installing the freezer
1
and the fridge
2
together ensure that the freezer is located on the left
andthefridgeontheright(asshownonthedrawing).
Leftsideofrefrigeratorisequippedwithspecialdevice
inordertoavoidcondensationproblemsbetween
appliances.
Werecommendedinstallingtwoappliancestogether
usingthelinking-kit
3
(asshownonthedrawing).You
can buy it in Service.

Tolevelthedoorsusingtheadjustablelowerhinge
(selectmodels)
Iftherefrigeratordoorislowerthanthefreezerdoor,
raise the refrigerator door by turning the adjustment
screwcounterclockwiseusingaM10wrench.
Ifthefreezerdoorislowerthantherefrigeratordoor,
raisethefreezerdoorbyturningtheadjustmentscrew
counterclockwiseusingaM10wrench.
*Availableonselectedmodelsonly.PleasecheckontheQUICKSTARTGUIDEifthisfunctionisactuallyavailableonyourmodel.
50mm
50mm
5 mm
max
