ASSEMBLY INSTRUCTIONS
Step 10
Insert the cylinder locking bar (10) into the two holes
on the base assembly (9) as shown in the illustration.
Step 10:
Warning: This appliance requires installation by a competent person. Proper assembly is the responsibility of the
installer.
10
9
Step 11
Place the gas cylinder (not included) into the base
assembly (9), and fix it with the cylinder locking bar (10).
Attach the regulator to the cylinder, turn clockwise to tighten
it securely, and close the door.
Note: Make sure to check for leaks once the cylinder has
been replaced. (refer to the “Check for leaks” section).
Step 11:
10
9
