7
Vortex Dual Operating Manual
English
When connected to Vortex Dual, extension cord wiring can overheat under
conditions of high current draw. If an extension cord is necessary, use the shortest
possible length and only size 14 AWG or larger for 115 V (ac) or 1.00 mm
2
or larger
for 230 V (ac).
Do not use Vortex Dual near open containers of gasoline or other flammable
liquids.
This product is designed for use with refrigerants only and is not intended
for use with any combustible refrigerants. Any other uses of this product are not
recommended by INFICON and could result in personal injury. Use of this product
other than intended is done at the user's own risk.
2.0 Specifications, Features and Warranty
2.1 Vortex Dual Specifications
Refrigerants . . . . . . . . . . . R-12, R-1234yf, R-134a, R-22, R-401A, R-401B,
R-401C, R-402A, R-402B, R-404A, R-407A, R-407B,
R-407C, R-408A, R-409A, R-410A, R-500, R-502,
R-507
Power. . . . . . . . . . . . . . . . . 115 V (ac), 60 Hz, 12 A,
or 230 V (ac), 50/60 Hz, 10A (depending on version)
Protection . . . . . . . . . . . . . High pressure switch cutoff at 550 PSI, 3.8 MPa, 38
bar Compressor motor thermally protected
Pressure . . . . . . . . . . . . . . Low side design pressure 350 PSI, 2.4 MPa, 24 bar
High side design pressure 550 PSI, 3.8 MPa, 38 bar
Temperature . . . . . . . . . . . Operating range 10 to 40°C (50 to 104°F)
Pollution degree . . . . . . . . 2
Ingress protection . . . . . . IP20
EPA Certification
(PN 714-202-G1 only) . . . . Certified for all refrigerants listed under categories III,
IV, & V in ARI standard 740-1998
