Infiniton GASHQ4 - Page 6

3
Figure 13 Figure 14
1.burner 6—1.75kW(127g/h) in 65 mm 1.burner 6—1.75kW(127g/h) in 65 mm
2.burner 7—1.0kW(73g/h) in 45 mm 2.burner 7—1.0kW(73g/h) in 45 mm
3.burner 8—3.0kW(218g/h) in 95 mm 3.burner 8—3.0kW(218g/h) in 95 mm
4.burner 9—1.75kW(127g/h) in 65 mm 4.burner 9—1.75kW(127g/h) in 65 mm
5.Burner 10—3.5kW(255g/h) in 132 mm 5.Burner 10—3.5kW(255g/h) in 132 mm
operating instructions:
button 1 is for burner 10
button 2 is for burner 6
button 3 is for burner 8
button 4 is for burner 7
button 5 is for burner 9
JZY-HQ5B90BAGIK,JZT-HQ5B90CAGIK,
operating instructions:
button 1 is for burner 10
button 2 is for burner 6
button 3 is for burner 8
button 4 is for burner 7
button 5 is for burner 9
JZY-HQ5L90CAGIK,JZT-HQ5L90CAGIK,
