Wall-mounting
-6-
Mounting soundbar on a wall
In order to prevent injuries,the sound bar device must be
securely fasten to the wall in accordance with the below
installation instructions.
1.Drill the two holes(about 6mm diameter ) in the wall and keep
the distance between drill holes of the sound bar is 500 mm.As
shown in the picture on the right.
Insert the two plugs supplied into two drilled holes and then
insert two screws supplied into two holes and tighten.As shown
in the picture on the right(diagram 1).
2. Take care to leave 4 mm between the screw heads and
wall.As shown in the picture on the right(diagram 2).
4mm
500mm
Diagram 1
Diagram 2
3.Use the assembled sound bar to hang on the setscrews on the
wall .As shown in the picture on the right(diagram 3).
Diagram 3
