Built-In Installation Built-In Installation
2.Installation the hinges and spacer
Fix the hinges to the machine by means of the ST4*12 screws. The hinges can be adjusted
to compensate for possible uneven thickness of the door.
Drill hole on the door
according to the 1.Drill the hole on the door fixed position paper.
P.32
P.33
2.Fixed position paper on the door.
Paste on the Door(The door on the right)Shear fixed position paper
Position Paper Position Paper
16- 22mm
12m m
35m m
12m m
2mm
Paste on the Door(The door on the left)
Appendix
1. Make the mark on the door according to the cupboard and washing machine height.
Preparation the Fixed position paper
1.Self-tapping screws
(ST4*12)
2.Self-tapping screws
(M5*12)
3.Hinges
4.Counter magnet
5.Spacer
6.Fixed position paper
Tools
1.
2.Automatic Driver
3.Ruler
4.Pencil
Screw Driver
5
1
2
4
3
6
1
2
3
4
Position Paper
Top Top
Left Open
Right Open
